If you need know more about Qinkai wire mesh cable tray. Welcome to visit our factory or send us enquiry.
Apply to: Floor or cabinet top, the height can be adjustable Fit for: Wire mesh cable tray from 100 mm to 600 mm , the height of bracket is 120 mm or customized. Include: Bar x l, Foot x 2 , a set of bolt and nut Feature: Neat and easy, good bearing
Apply to: Connect 2 straight sections of tray Fit for:Diameter of wire from 4 .0 mm to 5.5mm Feature: Connectionwith no bolt; To be used in conjunction with Bottom Joiners to join lenghts of cable mesh together.Apply to: Output cables from trays. Smoothly drop cables out of mesh
Fit for: Diameter from 3.5mm to 6.0mm ,Width of trays >150mm
Feature:
No sharp edges. Easily moved, and reinstalled. Custom colours can be supplied upon request.
The wall bracket is a cable tray cantilever bracket from Qinkai Manufacturing. This heavy-duty bracket is one part of wall mounting system of wire mesh cable tray. Compared with L-shaped wall bracket, cantilever bracket is often used for the tray over 300mm to provide a firm supporting. Different surface finishing is also optional to match with cable tray.
Apply to: Use 50 hangers to hang the wire tray on the ceiling. Only applicable to 50MM wide trunking, without screw installation. Fix with hook. Fit for:Diameter of wire from 3.5mm to 6. 0mm ,the width of tray is 50mm Include: 1 unit ( rods and nuts are optional) Feature:Economical and easy to installApply to: Support 100 mm trays on floor or top of cabinet，It can be fixed directly on the ground with screws.Without screw support, fixed with bending protrusion. The type and width of wire slot shall match. Fit for: Diameter from 3.5mmto 6.0mm ,Width> 100 mm trays Include: 1 unit ( Optional expanding nut or bolt and nut) Feature: Easy installation and lowcost
Apply to: Provide various screw positions. Expansion screws can be increased or decreased as required. Only 100mm installation space is required, which is more suitable for small space. Include: 1 unit ( Optionalexpanding nut or bolt and nut) Feature:Applicable to various installation environments.Apply to: Fix the wire tray on the screw with nuts and hang it on the ceiling.Matching of hanger length and trunking width Fit for: Diameter of wire from 4 . 0 mm to 6.0mm Include: 1 unit ( rods and nuts are optional) Feature: Support without screw, Fixed with bending protrusion. The most popular installation way is hanging under ceiling. We can also supply wall mounting, floor mounting, standing on cabinet, standing under electrostatic floor and many other options for cable basket.
Apply to: It is only applicable to the trunking with a width of 50MM, and also applicable to the top of the cabinet. Fit for: Diameter from 3.5mmto 6.0mm , Width = 50 mm trays Without screw support, fixed with bending protrusion. Feature: Easy installation and low costCan be installed in seconds – no tools are required, the product simply clicks into place, anywhere along the length of mesh.
The radius protection provided prevents sharp bends or kinks in cables. In the case of network cables this prevents connectivity loss.The published load results are based on uniformly loaded, simply supported span.
